Superior Material Composition: Our valves are cast with chemical compositions at the highest end of international standards. For example, our ASTM A351 CF8 stainless steel contains 9% Nickel—the maximum allowable—to ensure superior corrosion resistance and extended service life.
Surface Integrity: Our castings are guaranteed to be free from surface porosity, shrinkage, or unauthorized weld repairs, ensuring maximum material strength and pressure-holding capability.
Future-Proof Automation Ready: ISO 5211 actuator pads enable future pneumatic/electric upgrades without valve replacement
Innovative & Compact Design: In a market of conventional designs, its unique and modern appearance immediately sets it apart.
Design and Manufacture: ASME B16.34; ASME VIII; API 609
Leakage Class: API 598 (Bi-directional Zero Leakage)
Side Flange Standards: ANSI 125LB/ 150LB; ASME; AS-D/E; BS; DIN; EN PN6/ PN10/ PN16; GB; GOST; HG/T; JIS 5K/ 10K
Top Flange (Actuator Mounting) : ISO 5211; GB 90°
Face-to-Face Dimension: ISO 5752; MSS SP-68; ASME B16.10; EN 558-1; API 609
Testing Standards: API 598; EN 12266-1; ISO 5208; BS 6755-1
Certifications: ISO 9001; CE; BV; API 609; API 598; EAC; SIL3；
Technical description
Download
Q&A
Specification of the Valve |
|
|---|---|
|
Type of Connection |
Wafer |
|
Actuation |
Hand Lever |
|
Size |
DN40~DN200 (1.5in~8in ) |
|
Pressure |
PN6~PN20 (Class 125/150) |
|
Testing Pressure |
Shell: 1.5 x Rated Pressure; Seat: 1.1 x Rated Pressure (acc. to API 598) |
|
Medium |
Water, Oil, Gas, Steam, Corrosive Media, Slurry, etc. |
|
Medium Temperature |
-25~180℃ Depends on seat material |
Material of the Valve |
|
|---|---|
|
Body |
Stainless Steel: CF8 (304), CF8M (316), CF3 (304L), CF3M (316L), JS1030, 1.4406 Duplex Stainless Steel: 2205, 2507 Austenitic Stainless Steel: 1.4529, CN7M (Alloy 20) |
|
Disc |
Cast Iron: DI, CI Stainless Steel: CF8 (304), CF8M (316), CF3 (304L), CF3M (316L), CD3MN (Duplex 2205), CE3MN (Super Duplex 2507), 1.4529 (926) Aluminum Bronze: C95400, C95800 Nickel Alloy: CW6MC (Hastelloy C-276 eq.) |
|
Shaft |
Carbon Steel: 45# Stainless Steel: SS410, SS416, SS420; SS304, SS316, SS304L, SS316L; 17-4PH (SS630); Duplex 2205, Super Duplex 2507, 1.4529 Nickel Alloy: Monel K500, Hastelloy C-276 |
|
Soft Seat |
Elastomers: EPDM, HTEPDM, NBR (Nitrile Rubber / Buna-N), SIL (VMQ), FKM (VITON™), HYPALON™ Plastics: PTFE, PFA, UHMWPE |
Our butterfly valve stainless bodies are produced from a high-density casting process. This ensures a solid, non-porous structure, completely free from sand holes and other casting defects. The result is superior strength and maximum durability.
Learn More About Our ProcessThe AeroForm Series redefines manual valve operation, combining robust, high-grade materials with an ergonomic design for unparalleled reliability and ease of use in demanding industrial environments.
We utilize high-grade CF8M stainless steel with a Nickel content at the upper end of ASTM standards. This enriched composition provides exceptional corrosion resistance, ensuring long-term, leak-free performance even with challenging media.
The AeroForm handle is engineered for a secure grip and smooth, 90-degree actuation. Paired with a heavy-duty locking mechanism, it ensures precise flow control and dependable positioning, preventing accidental operation.
Every valve body is a product of our advanced casting process, guaranteeing a structure free from porosity or defects. This flawless foundation ensures maximum pressure containment and structural strength, providing peace of mind in critical applications.
From general industrial services to specialized process lines, the AeroForm lever-operated valve delivers dependable performance where direct, manual control is essential.
Ideal for controlling water, air, and other non-product utility lines in food processing plants. The hygienic design and corrosion resistance of our Stainless Steel Wafer Butterfly Valve ensure plant integrity and long service life.
Widely used for isolating chilled water lines and cooling tower connections. A 4 Inch Wafer Butterfly Valve with its clear open/close indication and locking handle is perfect for safe and efficient building maintenance operations.
Used for manual isolation on transfer lines for less aggressive chemicals, solvents, and utility fluids. The ability to secure a Butterfly Valve With Locking Handle ensures process safety during system checks and sampling.
The compact design of the Wafer Valve is a perfect fit for tight engine rooms and utility spaces on ships. Its stainless steel construction provides excellent resistance to corrosion from seawater in ballast and bilge systems.
A common choice for pump isolation, flow diversion, and filter backwash lines. A rugged 6 Wafer Butterfly Valve offers a simple, cost-effective, and reliable method for manual flow control in municipal and industrial plants.
In main and distribution lines of irrigation systems, a manually operated 10 Wafer Butterfly Valve allows for easy sectioning of the network for maintenance or seasonal adjustments, ensuring efficient water management.
Applied in utility and chemical feed lines, the robust construction of the Butterfly Handle Valve stands up to the demanding environment. Its stainless steel body resists corrosion from process chemicals and white water.
While lug styles are common, our wafer valves serve as crucial isolation points within sprinkler systems. The clear visual indicator on this Lug And Wafer Type Butterfly Valve is essential for confirming system readiness.
In dewatering circuits and slurry transfer lines, a durable Wafer Type Valve provides reliable manual shut-off. The field-replaceable seat design makes maintenance quick and cost-effective, minimizing plant downtime.
How a mid-sized engineering firm optimized their valve procurement strategy for a coastal water treatment facility by partnering with us for their manual isolation valve needs.
Client: A prominent mid-sized water engineering company in Jordan.
Project: Expansion of a pre-treatment facility for a desalination plant near Aqaba.
Contact: Tariq Al-Fayez, Senior Procurement Engineer.
Mr. Al-Fayez was tasked with procuring over 200 manual wafer butterfly valves (DN80 to DN300) for the facility's new low-pressure pipe network. The primary challenge was balancing a tight project budget against stringent long-term reliability requirements. The media consisted of screened seawater and chlorinated process water, a moderately corrosive environment that had caused premature failure in lower-grade valves on past projects.
The market presented Mr. Al-Fayez with two unsatisfying options: premium European brands that would inflate the valve budget by over 40%, threatening project viability, and low-cost regional suppliers whose material certificates were often questionable. His previous experience taught him that valves meeting the "SS316" specification on paper could still fail within 12-18 months due to inconsistent casting quality and lower-end alloy composition.
Instead of promising the impossible, our approach focused on transparently demonstrating how we manage quality at the source. This resonated with Mr. Al-Fayez's engineering background. The solution was built on three core pillars:
We demonstrated our key differentiator: our 81,426m² facility includes an in-house foundry, managed by our founder with over 20 years of casting expertise. This allowed us to provide not just standard Material Test Reports (MTRs), but also detailed evidence of our process. For their AeroForm CF8M valves, we supplied melt analysis data showing a consistent Nickel content between 10.5% and 11.5% and a PREN value consistently above 25, providing a quantifiable margin of safety against pitting corrosion from chlorides. This verifiable data gave them more confidence than a simple MTR from a supplier who outsources casting.
The AeroForm's robust design was a direct fit. The lockable hand lever was critical for their LOTO (Lock-Out/Tag-Out) safety procedures during pump and filter maintenance. Furthermore, our proprietary seat design achieves a bubble-tight shutoff (meeting ISO 5208 Rate A) through structural integrity, not by over-compressing the elastomer. This detail was crucial for Mr. Al-Fayez, as it directly addressed the common failure mode of premature seat wear and leakage. All dimensional checks were documented in our standard QC reports, generated from calibrated instruments on our 11 CNC machining centers.
We offered the AeroForm series at a price point that resulted in an 18% saving on their total valve procurement budget compared to the quotes from established Western brands. Crucially, this was backed by a 24-month warranty covering all components, including free replacement of wear parts (seats, O-rings). We were also transparent that while our in-house QC is rigorous, site-specific third-party inspection (e.g., by SGS or Bureau Veritas) could be arranged at their cost, giving them full control and verification options.
Our commitment to quality is verified by internationally recognized standards. We provide the documentation to prove it.
Ready to configure for your automation project?
Our reliability comes from controlling quality at the source. As a factory that integrates casting and machining, we use an enriched high-nickel content (up to 9% in CF8) in our steel. This, combined with our 20 years of casting expertise, results in a stainless steel wafer butterfly valve with superior corrosion resistance and a porosity-free body for maximum durability.
Absolutely. Every AeroForm series stainless steel wafer butterfly valve is built with a standardized ISO 5211 mounting pad. This future-proof design allows you to easily remove the hand lever and mount a pneumatic or electric actuator later without needing to replace the entire valve, protecting your initial investment.
We provide full traceability for every valve. Your order will include complete Material Test Reports (MTRs) and our factory QC inspection data. All our products are backed by a comprehensive 2-year warranty, giving you peace of mind and demonstrating our confidence in the long-term performance of our valves.
Buying factory-direct means you get better value, direct technical support, and greater transparency. You bypass middlemen, reducing costs. You communicate directly with the experts who cast, machine, and assemble your stainless steel wafer butterfly valve, ensuring your technical requirements are perfectly understood and met.
