Bare Shaft Actuation

Engineered with a standardized ISO 5211 mounting interface, this bare stem valve is the definitive choice for global integration. This universal standard guarantees a seamless and reliable connection with virtually any actuator brand—pneumatic, electric, or hydraulic—available in your local market.

• Superior Material Composition: Cast with ASTM A351 CF8 containing 9% Nickel—the maximum allowable—to ensure superior corrosion resistance.
• Lug Hole Positional Accuracy: True position of the threaded lug hole pattern is controlled to an exacting tolerance of ±0.10 mm and 100% gauge verified.
• High-Density Casting: Our zero-porosity casting process guarantees freedom from surface porosity, shrinkage, or unauthorized weld repairs.
• Patented Short-Neck Design: Our exclusive short-neck profile enables more compact system design and easier pipe insulation. It provides crucial extra clearance for actuators and surrounding equipment in space-sensitive applications.

Lever Handle Actuation

For rapid, manual on/off control. The lever handle provides quick 90-degree actuation and clear visual position indication, perfect for smaller diameter lines requiring frequent, straightforward operation.

Worm Gear Actuation

Provides mechanical advantage for easy and precise manual control of larger valves or high-pressure lines. The self-locking gearbox ensures the valve stays in position against flow-induced torque.

Pneumatic Actuation

The choice for high-speed, high-cycle automation. Pneumatic actuators offer unparalleled reliability and speed, with spring-return options for fail-safe operation in critical chemical processing or safety systems.

Electric Actuation

For precise, remote automated control. Electric actuators integrate seamlessly with PLC and SCADA systems, offering modulating control for flow regulation and reliable operation where compressed air is not available.

Core Advantages of JRVAL Lug SS Valves

• Ultimate Corrosion Resistance: Cast with ASTM A351 CF8 containing 9% Nickel—the highest end of the standard—for unmatched durability.
• Flawless Installation: Lug hole pattern is controlled to a ±0.10 mm tolerance and 100% gauge-verified, eliminating flange misalignment.
• Zero-Porosity Guarantee: High-density casting ensures a solid body free from porosity or shrinkage, maximizing strength and pressure-holding capability.
• Patented Short-Neck Design: Our exclusive short-neck profile enables more compact system design and easier pipe insulation. It provides crucial extra clearance for actuators and surrounding equipment in space-sensitive applications.

Bare Stem Actuation

Engineered with a standardized ISO 5211 mounting interface, this bare stem valve is the definitive choice for global integration. Its robust body provides a stable platform for any high-torque actuation system required by large-scale projects.

• Precision-Matched Flanges: Customized from pipeline measurements and reinforced per standards (e.g., HG/T) to ensure a perfect, leak-free seal.
• Traceable Craftsmanship: ISO9001 casting with permanent markings enables lifetime quality tracking from raw material to final product.
• Superior Material (9% Nickel): Cast with ASTM A351 CF8 at maximum allowable Nickel for superior corrosion resistance and zero porosity.

Lever Handle Actuation

An uncommon but available option for smaller flanged valves where quick manual shutoff is needed. Provides a simple, direct-control solution for accessible pipelines.

Worm Gear Actuation

The standard for manual flanged valves. The gearbox provides the necessary torque for effortless operation of high-pressure and large-diameter lines, ensuring precise and safe flow control.

Pneumatic Actuation

The choice for high-speed, high-cycle automation. Pneumatic actuators offer unparalleled reliability and speed, with spring-return options for fail-safe operation in critical chemical processing or safety systems.

Electric Actuation

Combines the ultimate sealing integrity of a flanged body with the precision of electric automation. Ideal for critical, large-scale process control and remote pipeline management.

Core Advantages of JRVAL Flange SS Valves

• Precision-Matched Flanges: Flanges are customized from pipeline measurements and reinforced per standards (e.g., HG/T) to guarantee a perfect, leak-free seal.
• Traceable Craftsmanship: ISO9001 casting with permanent markings enables lifetime quality tracking from raw material to final assembled valve.
• Superior Material (9% Nickel): Cast with ASTM A351 CF8 at the highest allowable Nickel content for superior corrosion resistance and extended life.

Heavy Body Series Stainless Steel Wafer (All Actuators)

The ultimate industrial wafer valve. Its heavy-walled body exceeds standards, providing an enhanced safety margin and superior structural integrity for demanding applications. Available with bare stem, lever, gear, pneumatic, or electric actuators.

• Robust Construction: Heavy-walled body significantly exceeds standard thickness requirements (e.g., HG/T, GOST), ensuring superior strength.
• Superior Material (9% Nickel): Cast with ASTM A351 CF8 at maximum Nickel content for guaranteed corrosion resistance.

Uni-Fit Series Wafer SS (All Actuators)

The ultimate solution for rapid integration. The Uni-Fit series combines universal flange compatibility with a lightweight body, ensuring fast, cost-effective installation in systems worldwide. It comes pre-fitted with a robust electric actuator for immediate, reliable automation.

• Universal Flange Fit: Designed to mate with multiple global flange standards (esp. JIS 16K, KS), eliminating compatibility guesswork and simplifying inventory for international projects.
• Rapid Installation Design: The compact, lightweight wafer body significantly reduces handling effort and installation time, lowering labor costs and minimizing system downtime during upgrades.

Modu-Seal Series Wafer SS (All Actuators)

A revolutionary design for hygienic applications demanding minimal downtime. This valve's modular seat allows for rapid, in-line replacement, drastically reducing maintenance costs. Available with bare stem, lever, gear, or pneumatic actuators.

Size: DN40~DN1200 [1.5in ~ 48in]; Pressure: PN6 ~ PN20 [Class 125/150]

MOQ: 1 Set; Standards: All Standards Met, esp. GOST.

• Modular Maintenance: Reduce maintenance costs by 90% and downtime by 80% with quick-change seats.
• Elasticity Excellence: High-resilience seat blend withstands 200°C CIP/SIP cycles with industry-leading elasticity retention.

Double Eccentric (Wafer) SS (All Actuators)

The high-performance workhorse. Its double-offset design lifts the disc off the seat, drastically reducing wear and extending service life in throttling and high-cycle services. Typically supplied with worm gear or automated actuators for precise control.

Size: DN40~DN2700 [1.5in ~ 108in]; Pressure: PN6 ~ PN63 [Class 125~300]

• Pinless Shaft Design: Key/square shaft connection eliminates pin failure points, ensuring stability in high-frequency and high-vibration environments.
• Bidirectional Sealing: The elastic seat and spherical disc design provides tight shutoff in both directions, preventing contamination and backflow.

Triple Eccentric (Flange/Lug) SS (All Actuators)

The apex of valve technology for zero-leakage performance. The friction-free, triple-offset design with a metal-to-metal seal ensures absolute, bubble-tight shutoff in high-pressure, high-temperature, and cryogenic services.

Size: DN40~DN2800 [1.5in ~ 112in]; Pressure: PN10 ~ PN400 [Class 150~2500]

• Bubble-tight Sealing: Tri-eccentric geometry with laminated or solid metal seals achieves API 598 bubble-tight zero leakage, even in severe conditions.
• Friction-Free Operation: The cone-in-cone seating eliminates friction during operation, preventing seat wear and ensuring low torque and a long service life.
